UniFi Switch 16 XG


The Ubiquiti UniFi Switch 16 XG is a layer 2 aggregation switch with (12) 10G SFP+ ports and (4) 10GbE RJ45 ports.


Email when stock is available

Add to Wishlist
Add to Wishlist

Ubiquiti UniFi Switch 16 XG

Layer 2 aggregation switch with (12) 10G SFP+ ports and (4) 10GbE RJ45 ports.

The UniFi Switch 16 XG (US-16-XG) is a fully managed, Layer 2 switch with (12) 10G SFP+ ports and (4) 10GbE RJ45 ports. Its 320 Gbps switching capacity and 160 Gbps total, non-blocking line rate make it an ideal aggregation switch for your core network. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.


      • (12) 10G SFP+ ports
      • (4) 10GbE RJ45 ports
      • (1) RJ45 Serial Console Port
      • (1) DC input

Managed with the UniFi Network application

UniFi Switch 16 XG
Dimensions443 x 221 x 43 mm
(17.44 x 8.70 x 1.69″)
Without Mount Brackets
With Mount Brackets
2.62 kg (5.78 lb)
2.71 kg (5.97 lb)
Total Non-Blocking Line Rate160 Gbps
Switching Capacity320 Gbps
Forwarding Rate238.10 Mpps
Max. DC Power Consumption36W (excludes SFP/SFP+ modules)
Power Method
100-240VAC/50-60 Hz, Universal Input
DC 56W, 57 to 20V, with 48/24VDC Terminal Block
Power SupplyAC/DC, Internal, 56W DC
Supported Voltage RangeAC: 100 to 240VAC
DC: 57 to 20VDC
Rack-MountYes, 1U High
ESD/EMP ProtectionAir: ± 24 kV, Contact: ± 24 kV
Shock and VibrationETSI300-019-1.4 Standard
LEDs Per PortSpeed/Link/Activity
Sound Level*
Fan Level 0
Fan Level 1
Fan Level 2
Fan Level 3
1.0 dBr
10.7 dBr
12.2 dBr
12.8 dBr
Networking Interfaces(12) 1/10 Gbps SFP+ Ethernet Ports
(4) 1/10 Gbps RJ45 Ethernet Ports
Management Interface(1) RJ45 Serial Port, Ethernet In-Band
Operating Temperature-5 to 40° C (23 to 104° F)
Operating Humidity5 to 95% Noncondensing
CertificationsCE, FCC, IC

Works with UniFi Network Controller

  • Manage Your Networks from a Single Control Plane
  • Intuitive and Robust Configuration, Control and Monitoring
  • Remote Firmware Upgrade
  • Users and Guests
  • Guest Portal/Hotspot Support

Source: Ubiquiti
Compatible with other UniFi products

Afmetingen221 × 443 × 43 mm
Ethernet (RJ45)



IPv6 ondersteuning

Switch layer

Switch eigenschappen

, , , , ,

Aantal VLANs


Maximale bandbreedte
