UniFi Switch 16 150W

344.89

The UniFi Switch 16 150W is a layer 2, PoE switch with (16) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports and (2) 1G SFP ports.

Uitverkocht

Email when stock is available

Add to Wishlist
Add to Wishlist

Ubiquiti UniFi Switch 16 150W

The UniFi Switch 16 150W is a layer 2, PoE switch with (16) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports and (2) 1G SFP ports.

The Switch 16 PoE 150W (US 16 PoE 150W), a fully managed switch with (16) GbE RJ45 ports and (2) 1G SFP ports. Each of the switch’s ports can provide either 802.3at PoE+ or configurable, 24V passive PoE to UniFi access points or other PoE devices. This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.

Features:

      • (16) GbE, 802.3at PoE+ and 24V passive PoE RJ45 ports
      • (2) 1G SFP ports
      • 122W total PoE supply

Managed with the UniFi Network application

UniFi Switch 16 150W
Dimensions443 x 43 x 221 mm
(17.44 x 1.69 x 8.70″)
Weight
Rack-Mount Brackets Excluded
Rack-Mount Brackets Included
2.80 kg (6.17 lb)
2.89 kg (6.37 lb)
Networking Interfaces(16) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports
Management InterfaceEthernet In-Band
Total Non-Blocking Throughput18 Gbps
Switching Capacity36 Gbps
Forwarding Rate26.78 Mpps
MAC Address Table16384
Maximum Aggregations6
Monitoring Sessions1
Maximum VLANs255
Power Method100-240VAC/50-60 Hz, Universal Input
Power SupplyAC/DC, Internal, 150W DC
Max. Power Consumption
Including PoE Output
Excluding PoE Output
150W
28W
LEDs Per Port
RJ45 Data Ports
SFP Data Ports
PoE, Speed/Link/Activity
Speed/Link/Activity
Sound Level*
Fan Level: 0
Fan Level: 1, 2, 3
1.7 dBr
10.8 dBr
ESD/EMP ProtectionAir: ± 24 kV, Contact: ± 24 kV
Shock and VibrationETSI300-019-1.4 Standard
Operating Temperature-5 to 40° C (23 to 104° F)
Operating Humidity5 to 95% Noncondensing
CertificationsCE, FCC, IC
PoE+ Per Port
PoE InterfacesPoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) 24VDC Passive PoE (Pins 4, 5+; 7, 😎
Max. PoE+ Wattage per Port by PSE34.2W
Voltage Range 802.3at Mode50–57V
Max. Passive PoE Wattage per Port17W
24V Passive PoE Voltage Range20-27V

Source: Ubiquiti
Compatible with other UniFi products

Gewicht1650 g
Afmetingen204 × 235 × 43 mm
Ethernet (RJ45)

Switchtype

IPv6 ondersteuning

Switch layer

Switch eigenschappen

, , , , ,

Aantal VLANs

Throughput

Maximale bandbreedte

Stroomverbruik

Power-over-Ethernet-type

PoE-budget

Brand

Manufacturer
